1x MER1S0505SC Murata DC-DC Converter 5V DC / 200mA Out 4.5V-5.5V DC In 1W +85°C - Murata Power Solutions

roll over the image to zoom in

£0.00
£8.95
RS 725-7023 / TSB-40B-RB6
Earn0
reward points

In stock: 18

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TSB-40B-RB6


    Murata Power Solutions

    MER1S0505SC Murata DC-DC Converter 5V DC / 200mA Out 4.5V-5.5V DC In 1W +85°C

    You will get ONE DC-DC Converter

    Description:
    1 W dual output SIP7 unregulated DC to DC converters with standard industry pinout and efficiency rating of up to 89%. These SIP7 DC to DC converters have an improved regulation performance making them suitable for applications where a wide output voltage variation can not be tolerated. An ideal application for these DC to DC converters is the provision of local supplies on control system boards with the additional benefit of having 1kVDC galvanic isolation to reduce any switching noise.

    SIP7 package with industry standard pinout
    Efficiency of up to 89%
    Wide temperature performance of -40 to + 85°C at full 1W load
    No heatsink or external components required
    Fully encapsulated with toroidal magnetics
    No electrolytic or tantalum capacitors
    UL94V-0 package material

    Note
    MTBF to MIL-HDBK-217F

    The MER1 Series of converters are not internally fused so to meet the requirements of UL 60950 an anti-surge input line fuse should always be used with ratings as defined below.
    MER1S05xxSC: 1A
    MER1S12xxSC: 0.375A
    MER1S15xxSC: 0.375A
    MER1S24xxSC: 0.2A
    MER1S48xxSC: 0.1A
    All fuses should be UL approved and rated to at least the maximum allowable DC input voltage.

    Standards
    UL 60950

    Specifications:
