1x MCP4152-503E/SN Digital Potentiometer 50kΩ 257-Position Linear SPI 8Pin - Microchip

roll over the image to zoom in

£0.00
£8.99
RS 724-0139
Earn0
reward points

In stock: 35

Sorry! We're out of stock

Add To Your Wishlist
    Type:
    Digital Potentiometer
    Unit Quantity:
    1
    Unit Type:
    Unit
    Resistance Rating:
    50 kΩ
    Location:
    TS BRA-2H


    Microchip

    MCP4152-503E/SN, Digital Potentiometer 50kΩ 257-Position Linear Serial-SPI 8-Pin SOIC

    • RS Stock No.724-0139
    • BrandMicrochip
    • Mfr Part No.MCP4152-503E/SN
    •
    • Microchip
    •
    • You will get ONE digital potentiometer
    MCP4152-503E/SN, Digital Potentiometer 50kΩ 257-Position Linear Serial-SPI 8-Pin SOIC
    Product Details

    MCP413x/415x/423x/425x Digital Potentiometers

    The Microchip MCP413x, MCP415x, MCP423x and MCP425x range of devices are Digital Potentiometers that feature a SPI interface. On board is volatile RAM memory.

    7-bit (129 steps) and 8-bit (257 steps) versions are available in various RAB resistance options from 5 kΩ to 100 kΩ. Further variants also give the choice between Rheostat and Potentiometer pinouts, Single and Dual Resistor Network options are also available.

    Digital Potentiometer - Microchip

    Specifications
    Maximum Operating Temperature
    +125 °C
    Length
    4.9mm
    Typical Single Supply Voltage
    1.8 → 5.5 V
    Taper Type
    Linear
    Brand
    Microchip
    Power Supply Type
    Single
    Resistance Value
    50kΩ
    Package Type
    SOIC
    Mounting Type
    Surface Mount
    Memory Type
    Volatile
    Minimum Operating Temperature
    -40 °C
    Width
    3.9mm
    Number of Pots per Package
    1
    Height
    1.25mm
    Pin Count
    8
    Dimensions
    4.9 x 3.9 x 1.25mm
    Control Interface
    Serial-SPI
    Number of Positions
    257
