1x LEDO/2 12-230V AC/DC Broyce Control DIN Rail Mount Timer Relay, 2 Contacts - Broyce Control

roll over the image to zoom in

£0.00
£68.95
RS 914-4597 / TSB-40C-RB1
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TSB-40C-RB1


    Broyce Control

    LEDO/2 12-230V AC/DC Broyce Control DIN Rail Mount Timer Relay, 2 Contacts

    You will get ONE timer relay

    Description:
    The Broyce Control single-function timer relay is solid-state, compact equipment with high precision and a wide range of programming features. It performs the function of providing ON operate delay with instantaneous contact in the range of 0.1 seconds to 100 hours. This timer has intuitive programming, which makes it easy to use and quick to configure. For selecting the time delay range, there are two selectable rotary switches on the front of the unit. It is affordable. Its high performance makes it ideal for a wide range of applications in process control environments.

    Features & Benefits:
    7 selectable time ranges in the range of 0.1s to 100h like 0.1s to 1s, 0.1min to 1min, 0.1h to 1h, 1s to 10s, 1min to 10min, 1h to 10h and 10h to 100h
    1 DPDT configuration relay output of 8A
    Supply voltage range is 12VAC to 230VAC and 12VDC to 230VDC
    17.5mm housing
    Mounting type is DIN rail
    Fine adjustment of the selected time range
    Green LED indication for supply and timing status
    Red LED indication for relay status

    Applications:
    Textiles
    Chemical industry
    Mining
    Irrigation
    Raw material handling
    Food and beverages
    Industrial process control

    Certifications:
    UL approved
    CE certified
    C-tick certified
    EN 61000-6-2
    EN 61000-4-3
    EN 61000-6-4
    IEC 61812
    cULus approved
    ISO 9001
    IP20 rated (Terminal protection)

    Specifications:
