1x DSPIC33EV32GM102-I/SO, Microchip 16-Bit Digital Signal Processor, 25MHz 32kB - Microchip

roll over the image to zoom in


£0.00
£11.99

RS 880-6705 / ES-12F + RS 178-4871 / TS-BRA-13i
Earn0
reward points

In stock: 240

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Item Height:
    2.05 mm
    Item Length:
    17.9 mm
    Mounting Style:
    PCB Mount
    Model:
    DSPIC33EV32GM102-I/SO
    Number of Pins:
    28
    Memory Size:
    32 kB
    Location:
    ES-12F + TS-BRA-13i


    Microchip

    1x DSPIC33EV32GM102-I/SO, Microchip 16-Bit Digital Signal Processor, 25MHz 32kB

    You will get ONE microcontroller

    Description:
    Microchip’s dsPIC33EV family of 16-bit Digital Signal Controllers (DSCs) features a 70 MIPS dsPIC® DSC core with enhanced on-chip features. Capable of operating in harsh environments these devices are suitable for appliance and automotive applications. Rich peripheral integration includes SENT (Single-Edge Nibble Transmission-Transmit/Receive), High Speed PWMs, OP Amps and Error Correcting Code Flash for increased reliability and safety. The performance offered by the dsPIC33EV family of MCUs allows them to be incorporated into the design of high-performance, precision motor control systems that are more energy efficient. They can be used to control BLDC, permanent magnet synchronous, AC induction and stepper motors.

    Microcontroller Features:
    • 70 MHz Max. CPU Speed
    • Code-Efficient (C and Assembly) Architecture
    • 16-Bit Wide Data Path
    • Two 40-Bit Wide Accumulators
    • Single-Cycle (MAC/MPY) with Dual Data Fetch
    • Single-Cycle, Mixed-Sign MUL plus Hardware Divide
    • 32-Bit Multiply Support
    • Intermediate Security for Memory - Provides a Boot Flash Segment in addition to the existing General Flash Segment
    • Error Code Correction (ECC) for Flash
    • Added Two Alternate Register Sets for Fast Context Switching
    Clock Management Features:
    • Internal, 15% Low-Power RC (LPRC) – 32 kHz
    • Internal, 1% Fast RC (FRC) – 7.37 MHz
    • Internal, 10% Backup RC (BFRC) – 7.37 MHz
    • Programmable PLLs and Oscillator Clock Sources
    • Fail-Safe Clock Monitor (FSCM)
    • Additional Fail-Safe Clock Monitor Source (BFRC), Intended to Provide a Clock Fail Switch Source for the System Clock
    • Independent Watchdog Timer (WDT)
    • System Windowed Watchdog Timer (DMT)
    • Fast Wake-Up and Start-Up
    Power Management Features:
    • Low-Power Management modes (Sleep, Idle and Doze)
    • Power Consumption Minimized Executing NOP String
    • Integrated Power-on Reset (POR) and Brown-out Reset (BOR)
    • 0.5 mA/MHz Dynamic Current (typical)
    • 50 μA at +25°C IPD Current (typical)
    Peripheral Features:
    • Up to Six Pulse-Width Modulation (PWM) Outputs (three generators)
    • Configurable Analogue to Digital Converter (ADC) Module
    • Up to 4 Operational Amplifiers
    • Up to 5 Comparators
    • Charge Time Measurement Unit (CTMU) - Supports mTouch™ capacitive touch sensing
    • Five 16-bit Timers
    • Two 32-bit Timers
    • Four Output Capture modules Configurable as Timers/Counters
    • Four Input Capture modules
    • Two Enhanced Universal Synchronous Asynchronous Receiver Transmitter (EUSART)
    • Two SPI Modules
    • One I2C Module with SMBus Support
