1720 x Panasonic Metal Oxide Varistor ERZVF2M330 2.5A Clamping 65V, Varistor 33V - Panasonic

roll over the image to zoom in

£0.00
£712.99
RS 721-0059
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1720
    Location:
    MAIN SHELF ARCHIVE BOX


    Panasonic

    Panasonic ZNR Series Metal Oxide Varistor 2.5A, Clamping 65V, Varistor 33V


    • BMUK Part # :-721-0059
    • BrandPanasonic
    • Mfr. Part No.ERZVF2M330

    •
    • You will get 1720 Varistors on 1 Reel








    Product Details

    Metal Oxide Varistors ZNR Series SMD

    Panasonic VF surge absorbers are designed for flow and reflow soldering. These surge absorbers feature low clamping voltage and large withstanding surge current capability. VF surge absorbers are part of the Zinc-oxide Non-Linear Resistor (ZNR) range. Saving cost and board space, they can perform the same function as two back to back zener diodes and a parallel connected capacitor.

    Compact size
    Surface mount
    Protective coating

    Applications

    Typical applications include the absorption of switching surge from relays and protection of consumer and industrial equipment. These surge absorbers can be used to protect communication modules such as terminal adopters, modems and xDSL technology.

    Standards

    PCQC (GB/T10193, GB/T10194)




    Specifications



    		Varistor Voltage33V

    		Maximum AC Voltage Rating20V

    		Maximum DC Voltage Rating26V

    		Clamping Voltage65V

    		Clamping Current2.5A

    		SeriesZNR

    		Maximum Surge Current125A

    		Length8mm

    		Depth6mm


    To view the datasheet please Click Here
