17 x STMicroelectronics TS932ID, Op Amp, 100kHz, 3V, 5V, 9V, 8-Pin SOIC - STMicroelectronics
roll over the image to zoom in
£0.00
£23.99
RS 486-3338
Unit Quantity:
17
Unit Type:
Unit
Location:
BRA 4L
STMicroelectronics
STMicroelectronics TS932ID, Op Amp, 100kHz, 3 V, 5 V, 9 V, 8-Pin SOIC
- BMUK Part Number. 486-3338
- BrandSTMicroelectronics
- Mfr Part No.TS932ID
-
- You will get a Tube of 17 Op Amps
Image representative of range only
Product Details
TS93x, Micro-Power Amplifiers with CMOS Inputs Operational Amplifiers
The TS931 (Single), TS931 (Dual) and TS934 (Quad) operational amplifiers can operate with voltages as low as 2.7 V and reach a 2.9 Vpp output swing with load resistance of 100 kΩ when supplied at 3 V.
Operational Amplifiers, STMicroelectronics
Specifications
Maximum Operating Temperature
+105 °C
Number of Channels per Chip
2
Length
5mm
Typical Single Supply Voltage
3 V, 5 V, 9 V
Typical Slew Rate
0.05V/µs
Typical Voltage Gain
120 dB
Brand
STMicroelectronics
Power Supply Type
Single
Package Type
SOIC
Mounting Type
Surface Mount
Minimum Operating Temperature
-40 °C
Width
4mm
Height
1.25mm
Pin Count
8
Dimensions
5 x 4 x 1.25mm
Typical Gain Bandwidth Product
100kHz
