1572 x Panasonic Zener Diode DZ2S08200L, 8.2V 150mW SMT 2-Pin SSMini2 F5 B - Panasonic

roll over the image to zoom in

£0.00
£106.99
RS 710-6152
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1572
    Unit Type:
    Unit
    Location:
    APR BOX T


    Panasonic

    Panasonic Zener Diode, 8.2V 150 mW SMT 2-Pin SSMini2 F5 B


    • BMUK Part # : 710-6152
    •  BrandPanasonic
    • Mfr. Part No.DZ2S08200L
    •
    •
    •
    • You will get 1572 Diodes on a Reel






    Product Details

    Zener Diodes 150mW, DZ2S Series, Panasonic


    Zener Diodes, Panasonic


    Specifications



    		Diode ConfigurationSingle

    		Nominal Zener Voltage8.2V

    		Mounting TypeSurface Mount

    		Number of Elements per Chip1

    		Maximum Power Dissipation150 mW

    		Package TypeSSMini2 F5 B

    		Zener TypeGeneral Purpose

    		Pin Count2

    		Test Current5mA

    		Maximum Zener Impedance60Ω

    		Maximum Reverse Leakage Current100nA

    		Length1.2mm

    		Dimensions1.2 x 0.8 x 0.6mm

    		Height0.6mm

    		Maximum Operating Temperature+150 °C

    		Typical Voltage Temperature Coefficient4.7mV/°C

    		Width0.8mm
