1460 x Panasonic DSC2A01T0L NPN Transistor, 50mA, 40V, 3-Pin Mini3 G3 B - Panasonic
roll over the image to zoom in
£0.00
£119.99
RS 712-5923
Unit Quantity:
1460
Unit Type:
Unit
Location:
APR BOX S
Panasonic
Panasonic DSC2A01T0L NPN Transistor, 50 mA, 40 V, 3-Pin Mini3 G3 B
- BMUK Part # : 712-5923
- BrandPanasonic
- Mfr. Part No.DSC2A01T0L
- You will get 1460 Transistors on a Reel
Image representative of range
Product Details
Small Signal NPN Transistors, Panasonic
Bipolar Transistors, Panasonic
Specifications
| Transistor Type | NPN | |
| Maximum DC Collector Current | 50 mA | |
| Maximum Collector Emitter Voltage | 40 V | |
| Package Type | Mini3 G3 B | |
| Mounting Type | Surface Mount | |
| Maximum Power Dissipation | 200 mW | |
| Minimum DC Current Gain | 1000 | |
| Transistor Configuration | Single | |
| Maximum Collector Base Voltage | 50 V | |
| Maximum Emitter Base Voltage | 15 V | |
| Maximum Operating Frequency | 150 MHz | |
| Pin Count | 3 | |
| Number of Elements per Chip | 1 | |
| Width | 1.5mm | |
| Dimensions | 2.9 x 1.5 x 1.1mm | |
| Maximum Operating Temperature | +150 °C | |
| Height | 1.1mm | |
| Length | 2.9mm | |
| Maximum Collector Emitter Saturation Voltage | 0.2 V |
