1400 x Texas Instruments MAX4595DCKR Analogue Switch Single SPST 4.5-5.5V 5-Pin - Texas Instruments
roll over the image to zoom in
£0.00
£445.99
RS 732-1323
Unit Quantity:
1400
Unit Type:
Unit
Location:
APR BOX R
Texas Instruments
Texas Instruments MAX4595DCKR, Analogue Switch Single SPST, 4.5 → 5.5 V, 5-Pin SC-70
- BMUK Part # :- 732-1323
- BrandTexas Instruments
- Mfr. Part No.MAX4595DCKR
- You will get 1400 ICs on a Reel
Product Details
Analogue Switches, Texas Instruments
Analogue Signal Switches and Multiplexers from Texas Instruments are high performance and suitable for a broad range of applications.
Switches and Multiplexers, Texas Instruments
Signal Switches and Multiplexers enable connector sharing, minimise duplicated circuitry in a design. They also isolate signal path along with simplifying signal routing.
Specifications
| Configuration | Single SPST | |
| Package Type | SC-70 | |
| Mounting Type | Surface Mount | |
| Typical Single Supply Voltage | 4.5 → 5.5 V | |
| Switch Type | Analogue | |
| Pin Count | 5 | |
| Power Supply Type | Single | |
| Input Signal Type | Single Ended | |
| Output Signal Type | Single Ended | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +85 °C | |
| Number of Channels per Chip | 1 | |
| Number of Outputs per Element | 1 | |
| Number of Inputs per Element | 1 | |
| Height | 1mm | |
| Dimensions | 2.15 x 1.4 x 1mm | |
| Length | 2.15mm | |
| Width | 1.4mm | |
| Multiplexer Architecture | 1:1 |
