1240 x Kingbright KPHHS-1005MGCK, KPHHS 570nm Green LED, 1005 (0402) SMD package - Kingbright
roll over the image to zoom in
£0.00
£224.99
RS 466-3611P
Unit Quantity:
1240
Unit Type:
Unit
Location:
APR BOX J
Kingbright
Kingbright KPHHS-1005MGCK, KPHHS 570 nm Green LED, 1005 (0402) SMD package
- BrandKingbright
- Mfr. Part No.KPHHS-1005MGCK
- You will get 1240 Leds on 1 Reel
Product Details
Kingbright SMT Chip LED 1005 (0402) Package
Kingbright's KPHHS-1005 series of surface mount Chip LED lamps are in the industry standard 0402 package. They offer low power consumption and a wide viewing angle, making the Chip LED 0402 LEDs ideal for backlight and indicator applications. There are a variety of colours and lens types available in the KPHHS-1005 series.
Features of the KPHHS-1005 0402 LEDs:
1.0 x 0.5 x 0.5 mm package size
Standard 0402 package size
Viewing angle: 120°
Variety of single colour options
Visible Light LEDs, Kingbright
Specifications
| LED Colours | Green | |
| Package Type | 1005 (0402) | |
| Mounting Type | Surface Mount | |
| Number of LEDs | 1 | |
| Forward Voltage | 2.1 V | |
| Luminous Intensity | 45 mcd | |
| Number of Pins | 2 | |
| Viewing Angle | 120 ° | |
| Lens Shape | Rectangle | |
| Dominant Wavelength | 570 nm | |
| Dimensions | 1 x 0.5 x 0.5mm | |
| Series | KPHHS | |
| LED Material | AlGaInP | |
| Lens Colour | Clear |
Please see our other items for a wide range of Electronic components.
