1210 x Panasonic ELL5PR Series Shielded Wire-wound SMD Inductor 4.7uH ±30% 2.2A - Panasonic

roll over the image to zoom in

£0.00
£512.99
RS 749-8643
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1210
    Unit Type:
    Unit
    Location:
    MAIN SHELVES ARCHIVE BOXES


    Panasonic

    Panasonic ELL5PR Series Type ELL5PR Shielded Wire-wound SMD Inductor 4.7 μH ±30% Wire-Wound 2.2A Idc


    • BrandPanasonic
    • Mfr. Part No.ELL5PR4R7N
    •
    •
    •
    • You will get 1210 Inductors on 1 Reel






    Product Details

    ELL5PR Series Magnetically Shielded Wire Wound Chokes

    Panasonic ELL5PR Magnetic shielded SMD choke coils with a low DC resistance and a large current capability. Applications for the ELL5PR series include: DC-DC converter circuitry for computer peripherals and cellular phones; Chopper circuit decoupling chokes for DC-DC converter circuitry


    Panasonic Non Standard SMT Inductors (Chokes)


    Specifications


    		Inductance4.7 μH

    		Maximum DC Current2.2A

    		Package/CaseELL5PR

    		Length5mm

    		Depth5mm

    		Height1.85mm

    		Dimensions5 x 5 x 1.85mm

    		ShieldedYes

    		Tolerance±30%

    		Maximum DC Resistance56mΩ

    		SeriesELL5PR

    		Inductor ConstructionWire-Wound
    To view the datasheet please Click Here
