1200 x Vishay SI3442CDV-T1-GE3 N-channel MOSFET, 8A, 20V, 6-Pin TSOP - Vishay

roll over the image to zoom in

£0.00
£207.99
RS 787-9226P
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1200
    Unit Type:
    Unit
    Location:
    APR BOX E


    Vishay

    Vishay SI3442CDV-T1-GE3 N-channel MOSFET, 8 A, 20 V, 6-Pin TSOP


    • BMUK Part # : 787-9226P
    • BrandVishay
    • Mfr. Part No.SI3442CDV-T1-GE3
    •
    •
    • You will get 1200 Transistors on 1 Reel






    Product Details

    N-Channel MOSFET, 8V to 25V, Vishay Semiconductor


    MOSFET Transistors, Vishay Semiconductor


    Specifications



    		Channel TypeN

    		Maximum Continuous Drain Current8 A

    		Maximum Drain Source Voltage20 V

    		Maximum Drain Source Resistance3 Ω

    		Minimum Gate Threshold Voltage0.6V

    		Maximum Gate Source Voltage-12 V, +12 V

    		Package TypeTSOP

    		Mounting TypeSurface Mount

    		Pin Count6

    		Transistor ConfigurationSingle

    		Channel ModeEnhancement

    		Maximum Power Dissipation2.7 W

    		Dimensions3.1 x 1.7 x 1mm

    		Length3.1mm

    		Minimum Operating Temperature-55 °C

    		Width1.7mm

    		Number of Elements per Chip1

    		Transistor MaterialSi

    		Typical Turn-On Delay Time9 ns

    		Typical Input Capacitance @ Vds335 pF @ 10 V

    		Maximum Operating Temperature+150 °C

    		Typical Gate Charge @ Vgs9.2 nC @ 10 V

    		Height1mm

    		Typical Turn-Off Delay Time17 ns




    Thank you for looking, if you have any questions please ask or call us.
