105 x TE Connectivity Black Button Tactile Switch, SPST 50 mA@ 24V dc 0.27mm - TE Connectivity
roll over the image to zoom in
£0.00
£46.99
RS 718-2452
Unit Quantity:
105
Location:
TS-LB 2H
TE Connectivity
Black Button Tactile Switch, SPST 50 mA@ 24 V dc 0.27mm
- BrandTE Connectivity
- Mfr. Part No.FSM1LPTR
- You will get 1 Reel with 105 Tactile Switches on
Product Details
TE Connectivity FSM Series Tactile Switches
The professional range of tactile switches from TE Connectivity.
SPNO tactile switches available in THT, SMD & right angle mountings
SMD types suitable for immersion
Tactile
Specifications
| Contact Configuration | SPST | |
| Terminal Type | Through Hole | |
| Switch Operation | Off-(On) | |
| Actuator Length | 0.27mm | |
| Actuator Colour | Black | |
| Actuator Type | Button | |
| Contact Current Rating | 50 mA @ 24 V dc | |
| Operating Force | 1.6 N | |
| Operating Temperature Range | -20 → +85°C | |
| Contact Material | Silver Copper Alloy | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | +85°C |
