1000 x International Rectifier AUIRF7640S2TR1 N-channel MOSFET Transistor 60V - International Rectifier

roll over the image to zoom in

£0.00
£877.00
RS 737-7518
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1000
    Unit Type:
    Unit


    International Rectifier

    International Rectifier AUIRF7640S2TR1 N-channel MOSFET Transistor, 21 A, 60 V, 6-Pin DirectFET SB


    • BMUK Part # :-737-7518
    • BrandInternational Rectifier
    • Mfr. Part No.AUIRF7640S2TR1
    •
    •
    • You will get 1000 Transistors on 1 Reel





    Image representative of range



    Product Details

    Automotive DirectFET®2 Power MOSFET, Infineon

    DirectFET®2 power MOSFETs deliver exceptional power density, dual-sided cooling and low parasitic inductance and resistance in a robust AEC-Q101 qualified package for automotive applications. Combining the reliability and performance of proven DirectFET packaging technology with Infineon's latest trench silicon process, DirectFET®2 MOSFETs offer overall system-level size, cost and efficiency improvements.


    MOSFET Transistors, Infineon

    Infineon offers a large and comprehensive portfolio of MOSFET devices which includes the CoolMOS, OptiMOS and StrongIRFET families. They deliver best-in-class performance to bring more efficiency, power density and cost effectiveness. Designs requiring high quality and enhanced protection features benefit from AEC-Q101 industry standards Automotive qualified MOSFETs.


    Specifications


    		Channel TypeN

    		Maximum Continuous Drain Current21 A

    		Maximum Drain Source Voltage60 V

    		Maximum Drain Source Resistance36 mΩ

    		Maximum Gate Source Voltage±20 V

    		Package TypeDirectFET SB

    		Mounting TypeSurface Mount

    		Pin Count6

    		Channel ModeEnhancement

    		CategoryPower MOSFET

    		Maximum Power Dissipation30 W

    		Length4.85mm

    		Dimensions4.85 x 3.95 x 0.74mm

    		Typical Turn-On Delay Time4 ns

    		Height0.74mm

    		Typical Gate Charge @ Vgs7.3 nC @ 10 V

    		Typical Input Capacitance @ Vds450 pF @ 25 V

    		Typical Turn-Off Delay Time6.3 ns

    		Number of Elements per Chip1

    		Width3.95mm

    		Minimum Operating Temperature-55 °C

    		Maximum Operating Temperature+175 °C






    To view the datasheet please Click Here
