10 x Vishay VO615A-5 DC Input Phototransistor Output Optocoupler, 4-Pin - Vishay
roll over the image to zoom in
£0.00
£7.49
RS 773-3693
Unit Quantity:
10
Unit Type:
Unit
Location:
TS BRA 2E
Vishay
Vishay VO615A-5 DC Input Phototransistor Output Optocoupler, Through Hole, 4-Pin DIP
- BMUK Part # :-773-3693
- BrandVishay
- Mfr. Part No.VO615A-5
- You will get a pack of 10 Optocouplers
Image representative of range
Product Details
Optocoupler, Transistor Output, VO6xxA Series, Vishay Semiconductor
Vishay low input current optocoupler with a phototransistor output VO615A, VO617A, VO618A series protect equipment users from electrical shocks and protect the microprocessors within these systems from being damaged by voltage spikes.
VO617A and VO618A series provides up to 5300Vrms of voltage Isolation
VO615A series provides up to 5000Vrms of voltage Isolation
Applications include Isolation in AC adapters, switch mode power supplies, programmable logic controllers, Industrial controls, telecom systems, smart meters, office equipment, power on Internet and solar
Optocouplers VO615A, VO617A, VO618A have an operating temperature up to 110 degrees Celsius.
Optocouplers, Vishay Semiconductor
Specifications
| Mounting Type | Through Hole | |
| Output Device | Phototransistor | |
| Maximum Forward Voltage | 1.6V | |
| Number of Channels | 1 | |
| Number of Pins | 4 | |
| Package Type | DIP | |
| Input Current Type | DC | |
| Typical Rise Time | 3µs | |
| Maximum Input Current | 60 mA | |
| Isolation Voltage | 5000 Vrms | |
| Maximum Current Transfer Ratio | 150% | |
| Typical Fall Time | 4.7µs |
To view the datasheet please Click Here
Please visit our shop to see all our other items we have in stock,
Please call us if you have any questions,
Many thanks!
