10 x Vishay Aluminium Electrolytic Capacitor MAL203858479E3, 47uF 63V dc - Vishay
roll over the image to zoom in
£0.00
£5.49
RS 684-2074
Unit Quantity:
10
Unit Type:
Unit
Capacitor Construction:
Aluminium Electrolytic (Polarised)
Location:
TS 12J + ES 14i
Vishay
Vishay Aluminium Electrolytic Capacitor 47μF 63 V dc 6.3mm Through Hole series 038 RSU lifetime 2500h
- BMUK Part # :-684-2074
- BrandVishay
- Mfr. Part No.MAL203858479E3
-
- You will get a pack of 10 Capacitors
Product Details
038 RSU series radial
Ultra miniature radial electrolitic capacitor
Insulated with blue vinyl sleeve
General purpose use, industrial, automotive, consumer, and audio-video
| Capacitance Tolerance (%) | 20 |
| Operating Temperature (°C) | -40 to +85 |
| Life expectancy at 85°C | 2500Hrs ≤ 8mm diam 3500 Hrs ≥ 10mm diam |
Radial 85°C
Specifications
| Capacitance | 47 µF | |
| Technology | Electrolytic | |
| Voltage | 63 V dc | |
| Dimensions | 6.3 (Dia.) x 11mm | |
| Height | 11mm | |
| Diameter | 6.3mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
| Lead Pitch | 2.5mm | |
| Construction | Radial | |
| Series | 038 RSU | |
| Lead Diameter | 0.5mm | |
| Leakage Current | 30 μA | |
| Lifetime | 2500h | |
| Tolerance Minus | -20% | |
| Ripple Current | 170mA | |
| Tolerance Plus | +20% | |
| Terminal Type | Through Hole | |
| Tolerance | ±20% |
