10 x Vishay 100nF 0.1uF 220V AC, 630V DC MKT 1813 Polyester Film Capacitor Valve - Vishay
roll over the image to zoom in
£0.00
£10.99
MKT1813410635 x 10
Unit Quantity:
10
Unit Type:
Unit
Vishay
Vishay 0.1uF 100nF ±10% 220V AC, 630V DC Through Hole Polyester Film Capacitor MKT 1813
You will get a pack of 10 Capacitors
These can come on a tape as shown above or supplied loose as shown below, for large quantities let us know if you have any preference on the format supplied
Mfr. Part No. MKT1813410635
These can come on a tape as shown above or supplied loose as shown below, for large quantities let us know if you have any preference on the format supplied
The MKT1813410635 is an axial leaded DC Film Capacitor with polyester film dielectric and metallised electrodes.
The MKT1813 series film capacitor has tinned wire leads. It assists energy conversion while providing low losses, high efficiency and long life.
For general purpose applications of DC-filtering, coupling, bypassing timing and interference suppression on low-voltage circuits.
It is used for low building height applications.
The electrodes of metallised film capacitor consist of an extremely thin metal layer (0.02 to 0.1µm) that is vacuum deposited either onto the dielectric film or onto a carrier film.
The opposing and extended metalized film layers of the wound capacitor element are connected to one another by flame spraying different metals to the end-faces.
The metal spraying process is also known as schooping.
The terminals are connected to the end-faces by means of welding or soldering.
For general purpose applications of DC-filtering, coupling, bypassing timing and interference suppression on low-voltage circuits.
It is used for low building height applications.
The electrodes of metallised film capacitor consist of an extremely thin metal layer (0.02 to 0.1µm) that is vacuum deposited either onto the dielectric film or onto a carrier film.
The opposing and extended metalized film layers of the wound capacitor element are connected to one another by flame spraying different metals to the end-faces.
The metal spraying process is also known as schooping.
The terminals are connected to the end-faces by means of welding or soldering.
- Flame-retardant epoxy resin sealed plastic-wrapped encapsulation
- High volume efficiency
- Self-healing properties
Product Details
MKT 1813 Series
Applications include blocking, bypassing, filtering, timing, coupling and decoupling, interference suppression in low voltage circuits
Metallised 100°C
| Capacitance | 0.1uF 100nF | |
| Dielectric | MKT | |
| Lead Diameter | 0.8mm | |
| Length | 40mm | |
| Body Diameter | 10.5mm | |
| Maximum Operating Temperature | +100°C | |
| Minimum Operating Temperature | -55°C | |
| Mounting Type | Through Hole | |
| Series | MKT 1813, MKT1813 | |
| Tolerance | ±10% | |
| Tolerance Minus | -10% | |
| Tolerance Plus | +10% | |
| Voltage | 220 V ac, 630 V dc |
