10 x TruConnect 20-0970, 2.1 PCB DC Power Socket, Single Pole Switch, Solder Lug - TruConnect
roll over the image to zoom in
£0.00
£5.50
Rapid 20-0970
Unit Quantity:
10
Unit Type:
Unit
Location:
TS 50F
TruConnect
Order Code:
20-0970
MPN : 20-0970
You will get a pack of 10 PCB DC Power Sockets
PCB mounting 2.1 mm connector 30V DC power socket.
- 0.5A current rating
- Right angle type
- Solder lug termination
- Brass contact material
- Black colour
- 100MΩ insulation resistance
- Can be hand wired
- Single pole switch
To view the datasheet please Click Here
Please visit our shop to see all our other items we have in stock,
Please call us if you have any questions,
Many thanks!
Nichicon Aluminium Polymer Capacitor 330μF 2.5 V dc 6.3mm Through Hole LS Series Lifetime 5000h
Product Details
LS Series Solid Electrolytic Radial
Solid Radial 105°C
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Capacitance | 330 µF | |
| Technology | Polymer | |
| Voltage | 2.5 V dc | |
| Dimensions | 6.3 (Dia.) x 9mm | |
| Height | 9mm | |
| Diameter | 6.3mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 2.5mm | |
| Construction | Radial | |
| Series | LS | |
| Terminal Type | Through Hole | |
| Lifetime | 5000h | |
| Leakage Current | 500 μA | |
| Board Level Components | Y | |
| Lead Diameter | 0.6mm | |
| Ripple Current | 4.8A | |
| Tolerance Minus | -20% | |
| Tolerance | ±20% | |
| Tolerance Plus | +20% | |
| Equivalent Series Resistance | 8mΩ |
