10 x TRACOPOWER Through Hole 1W Isolated DC-DC Converter, Vin 4.5-5.5V dc - TRACOPOWER
roll over the image to zoom in
£0.00
£33.99
RS 124-7588
Unit Quantity:
10
Unit Type:
Unit
Location:
TS 58N
TRACOPOWER
TRACOPOWER Through Hole 1W Isolated DC-DC Converter, Vin 4.5 → 5.5 V dc, I/O isolation 1kV dc, Vout 5V dc
- BMUK Part # :-124-7588
- BrandTRACOPOWER
- Mfr. Part No.TMA 0505S
- You will get 1 DC-DC Converter
Image representative of range
Product Details
Traco 1W SIP Single/Dual Output Unregulated Isolated DC-DC Converter - TMA Series
The Traco Power TMA series is a range of miniature isolated, 1 Watt, DC/DC converters in a SIP package. The SMD technology of these isolated converters makes it possible to offer a product with high performance at low cost. The TME DC-DC converters require only 1.2 cm2 board space and are the perfect solution for space critical applications for board level power distribution
Single-in-line (SIP) package
Single and dual output models
I/O isolation 1’000 VDC
High efficiency up to 81%
Operating temperature range –40°C to +85°C
Industry standard pinout
100% Burn-in (8 h)
Lead free design, RoHS compliant
Approvals
7777
Specifications
| Output Voltage | 5V dc | |
| Input Voltage Range | 4.5 → 5.5 V dc | |
| Input Voltage Nominal | 5 V dc | |
| Isolation Voltage | 1000V dc | |
| Power Rating | 1W | |
| Output Current | 200mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Package | SIP 6 | |
| Efficiency | 71% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +85°C | |
| Load Regulation | ±10% | |
| Line Regulation | ±1.2% | |
| Ripple And Noise | 100mV Pk-Pk | |
| Series | TMA | |
| MTBF | 2000000h | |
| Depth | 10.2mm | |
| Weight | 2.1g | |
| Length | 19.5mm |
To view the datasheet please Click Here
