10 x Texas Instruments CSD17313Q2 N-Channel MOSFET, 5 A, 30 V NexFET, 6-Pin SON - Texas Instruments
roll over the image to zoom in
£0.00
£8.99
RS 827-4849
Unit Quantity:
10
Unit Type:
Unit
Location:
ES-14E
Texas Instruments
CSD17313Q2 N-Channel MOSFET, 5 A, 30 V NexFET, 6-Pin SON Texas Instruments
- BMUK Part # :- 827-4849
- BrandTexas Instruments
- Mfr Part No.CSD17313Q2
- You will get a pack of 10 Transistors
Product Details
N-Channel NexFET™ Power MOSFET, Texas Instruments
MOSFET Transistors, Texas Instruments
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
1
Length
2mm
Transistor Configuration
Single
Typical Turn-On Delay Time
2.8 ns
Brand
Texas Instruments
Typical Turn-Off Delay Time
4.2 ns
Maximum Continuous Drain Current
5 A
Package Type
SON
Maximum Power Dissipation
2.3 W
Series
NexFET
Mounting Type
Surface Mount
Minimum Operating Temperature
-55 °C
Width
2mm
Maximum Gate Threshold Voltage
1.8V
Height
0.8mm
Minimum Gate Threshold Voltage
0.9V
Maximum Drain Source Resistance
42 mΩ
Maximum Drain Source Voltage
30 V
Pin Count
6
Dimensions
2 x 2 x 0.8mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
2.1 nC @ 4.5 V
Transistor Material
Si
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
260 pF @ 15 V
Channel Type
N
Maximum Gate Source Voltage
-8 V, +10 V
