10 x Texas Instruments CD4502BEE4 CMOS Hex Buffer & Line Driver, 3-State, 3-18V - Texas Instruments
roll over the image to zoom in
£0.00
£5.99
RS 709-2346
Unit Quantity:
10
Unit Type:
Unit
Texas Instruments
Texas Instruments CD4502BEE4 Hex Buffer & Line Driver, 3-State, Inverting, 3 → 18 V, 16-Pin PDIP
Product Details
4000 Series Inverters & Buffers, Texas Instruments
Texas Instruments range of Inverters and Buffers from the 4000 Series CMOS Logic Family
4000 CMOS Logic Family, Texas Instruments
CMOS Family devices
Wide operating voltage range: 3 to 18V
Specifications
| Logic Family | 4000 | |
| Logic Function | Buffer, Driver | |
| Number of Channels per Chip | 6 | |
| Input Type | Single Ended | |
| Output Type | 3 State | |
| Polarity | Inverting | |
| Mounting Type | Through Hole | |
| Package Type | PDIP | |
| Pin Count | 16 | |
| Maximum High Level Output Current | -4.2mA | |
| Maximum Low Level Output Current | 25.2mA | |
| Maximum Propagation Delay Time @ Maximum CL | 380 ns @ 5 V | |
| Dimensions | 19.3 x 6.35 x 4.57mm | |
| Height | 4.57mm | |
| Maximum Operating Temperature | +125 °C | |
| Length | 19.3mm | |
| Maximum Operating Supply Voltage | 18 V | |
| Width | 6.35mm | |
| Minimum Operating Supply Voltage | 3 V | |
| Board Level Components | Y | |
| Propagation Delay Test Condition | 50pF | |
| Minimum Operating Temperature | -55 °C |
For a Specification PDF Please CLICK HERE
Thank you for looking, if you have any questions please ask or call us.
