10 x RS RNYD5-5 Insulated Crimp Ring Terminal, M5 (#10) Stud, 4mm²-6mm² 12-10AWG - RS Pro
roll over the image to zoom in
£0.00
£5.99
RS 267-3880
Unit Quantity:
10
Unit Type:
Unit
RS Pro
RS Pro RNYD Series Insulated Crimp Ring Terminal, M5 (#10) Stud Size, 4mm² to 6mm², 12AWG to 10AWG, Yellow
- BMUK Part # :-267-3880
- BrandRS Pro
- Mfr. Part No.RNYD5-5
- You will get a pack of 10 Connectors
Product Details
RS Pro Insulated Double Crimp Ring Terminals
Insulated copper double crimp ring terminals with a copper sleeved double crimp barrel. These insulated crimp ring connectors are colour coded for use with different wire ranges and are available with various stud sizes. For suitable crimp tool see stock number 267-3133.
Red 0.5 - 1.5 mm²
Blue 1 - 2.6 mm²
Yellow 2.5 - 6.5 mm²
Approvals
UL Listed; UL Listed for Canada
RS Pro Range
| Technical Specification | |
| Temperature rating | +70°C |
| Body Material | Copper |
| Body Plating | Tin |
Specifications
| Series | RNYD | |
| Insulation | Insulated | |
| Inner Ring Diameter | 5.3mm | |
| Insulation Material | Nylon | |
| Outer Ring Diameter | 9.5mm | |
| Minimum Wire Size mm² | 4mm² | |
| Maximum Wire Size mm² | 6mm² | |
| Minimum Wire Size AWG | 12AWG | |
| Maximum Wire Size AWG | 10AWG | |
| Stud Size | M5 (#10) | |
| Colour | Yellow | |
| Contact Material | Copper | |
| Thickness | 1mm | |
| Overall Length | 26mm |
To view the datasheet please Click Here
Please visit our shop to see all our other items we have in stock,
Please call us if you have any questions,
Many thanks!
Nichicon Aluminium Polymer Capacitor 330μF 2.5 V dc 6.3mm Through Hole LS Series Lifetime 5000h
Product Details
LS Series Solid Electrolytic Radial
Solid Radial 105°C
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Capacitance | 330 µF | |
| Technology | Polymer | |
| Voltage | 2.5 V dc | |
| Dimensions | 6.3 (Dia.) x 9mm | |
| Height | 9mm | |
| Diameter | 6.3mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 2.5mm | |
| Construction | Radial | |
| Series | LS | |
| Terminal Type | Through Hole | |
| Lifetime | 5000h | |
| Leakage Current | 500 μA | |
| Board Level Components | Y | |
| Lead Diameter | 0.6mm | |
| Ripple Current | 4.8A | |
| Tolerance Minus | -20% | |
| Tolerance | ±20% | |
| Tolerance Plus | +20% | |
| Equivalent Series Resistance | 8mΩ |
