10 x RS Pro SNYDL M4 Insulated Crimp Spade Connector 4mm²-6mm² 12AWG to 10AW - RS Pro

roll over the image to zoom in

£0.00
£5.99
RS 267-3969
Earn0
reward points

In stock: 8

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    10
    Unit Type:
    Unit
    Location:
    ES-8D


    RS Pro

    RS Pro SNYDL Series Insulated Crimp Spade Connector, 4mm² to 6mm², 12AWG to 10AWG, M4 (#8) Stud Size Nylon, Yellow

    • BMUK Part # :-267-3969
    • BrandRS Pro
    • RS Pro
    •
    • You will get a pack of 10 Connectors

    RS Pro SNYDL Series Insulated Crimp Spade Connector, 4mm² to 6mm², 12AWG to 10AWG, M4 (#8) Stud Size Nylon, Yellow
    Product Details

    RS Pro Insulated Double Crimp Spade Terminals

    RS Pro range of insulated crimp spade wire terminals made from brass with a copper sleeved barrel. These crimp spade connectors have vinyl or nylon insulation with a flared design for easy wire insertion. The insulation of these spade crimp connectors is colour coded to correspond with the wire size they are used with.







    https://media.rs-online.com/t_large/L2674079-01.jpg
    https://media.rs-online.com/t_large/L267366-01.jpg



    RS Pro Range

    Specifications

    Width
    8.3mm
    Stud Size
    M4 (#8)
    Insulation Material
    Nylon
    Thickness
    1mm
    Contact Material
    Copper
    Brand
    RS Pro
    Contact Plating
    Tin
    Overall Length
    25.5mm
    Maximum Wire Size AWG
    10AWG
    Maximum Wire Size mm²
    6mm²
    Colour
    Yellow
    Series
    SNYDL
    Minimum Wire Size AWG
    12AWG
    Minimum Wire Size mm²
    4mm²
    Insulation
    Insulated
