10 x ON Semiconductor NTMS5P02R2G P-channel MOSFET, 2.7A, 20V, 8-Pin SOIC - ON Semiconductor
roll over the image to zoom in
£0.00
£8.99
RS 805-4254
Unit Quantity:
10
Unit Type:
Unit
Location:
Basic Micro Box
ON Semiconductor
ON Semiconductor NTMS5P02R2G P-channel MOSFET, 2.7 A, 20 V, 8-Pin SOIC
- BrandON Semiconductor
- Mfr. Part No.NTMS5P02R2G
-
- You will get a pack of 10 Transistors
Product Details
P-Channel Power MOSFET, 20V, ON Semiconductor
MOSFET Transistors, ON Semiconductor
Specifications
| Channel Type | P | |
| Maximum Continuous Drain Current | 2.7 A | |
| Maximum Drain Source Voltage | 20 V | |
| Maximum Drain Source Resistance | 48 mΩ | |
| Maximum Gate Threshold Voltage | 1.25V | |
| Maximum Gate Source Voltage | -10 V, +10 V | |
| Package Type | SOIC | |
| Mounting Type | Surface Mount | |
| Pin Count | 8 | |
| Transistor Configuration | Single | |
| Channel Mode | Enhancement | |
| Category | Power MOSFET | |
| Maximum Power Dissipation | 2.5 W | |
| Height | 1.5mm | |
| Typical Turn-Off Delay Time | 70 ns | |
| Typical Input Capacitance @ Vds | 1375 pF @ -16 V | |
| Number of Elements per Chip | 1 | |
| Maximum Operating Temperature | +150 °C | |
| Width | 4mm | |
| Length | 5mm | |
| Dimensions | 5 x 4 x 1.5mm | |
| Transistor Material | Si | |
| Typical Turn-On Delay Time | 22 ns | |
| Minimum Operating Temperature | -55 °C | |
| Typical Gate Charge @ Vgs | 20 nC @ 4.5 V |
