10 x ON Semiconductor MC14503BDR2G Non-Inverting 3-State Buffer 3-18V 16-Pin - ON Semiconductor
roll over the image to zoom in
£0.00
£5.99
RS 806-3254
Unit Quantity:
10
Unit Type:
Unit
Location:
TS-LB 3I
ON Semiconductor
ON Semiconductor MC14503BDR2G, Hex Non-Inverting 3-State Buffer, 3 → 18 V, 16-Pin SOIC
- BrandON Semiconductor
- Mfr. Part No.MC14503BDR2G
- You will get a pack of 10 ICs
Product Details
4000 Series Inverters & Buffers, ON Semiconductor
4000 CMOS Logic Family, ON Semiconductor
CMOS Family devices
Wide operating voltage range: 3 to 18V
Specifications
| Logic Family | CMOS | |
| Logic Function | Buffer | |
| Number of Channels | 6 | |
| Schmitt Trigger Input | No | |
| Output Type | 3 State | |
| Polarity | Non-Inverting | |
| Mounting Type | Surface Mount | |
| Package Type | SOIC | |
| Pin Count | 16 | |
| Maximum High Level Output Current | 19.2mA | |
| Maximum Low Level Output Current | -8.2mA | |
| Maximum Propagation Delay Time @ Maximum CL | 200ns | |
| Dimensions | 10 x 4 x 1.5mm | |
| Length | 10mm | |
| Propagation Delay Test Condition | 50pF | |
| Maximum Operating Temperature | +125 °C | |
| Height | 1.5mm | |
| Maximum Operating Supply Voltage | 18 V | |
| Minimum Operating Temperature | -55 °C | |
| Minimum Operating Supply Voltage | 3 V | |
| Width | 4mm |
To view the datasheet please Click Here
Please see our other items for a wide range of Electronic components.
