10 x ON Semiconductor BC547BG NPN Bipolar Transistor, 0.1 A, 45 V, 3-Pin TO-92 - ON Semiconductor
roll over the image to zoom in
£0.00
£5.49
RS 545-2232
Location:
TS 46D
ON Semiconductor
ON Semi BC547BG NPN Bipolar Transistor, 0.1 A, 45 V, 3-Pin TO-92
- BMUK Part # :-545-2232
- BrandON Semiconductor
- Mfr. Part No.BC547BG
- You will get a pack of 10 Transistors
Product Details
Small Signal NPN Transistors, ON Semiconductor
These ON Semiconductor Bipolar transistors can amplify analogue or digital signals. They can also switch DC or function as an oscillator.
Bipolar Transistors, ON Semiconductor
A wide range of Bipolar Transistors from ON Semiconductor, which includes the following categories:
Small Signal Transistors
General Purpose Transistors
Dual NPN and PNP Transistors
Power Transistors
High Voltage Transistors
RF Bipolar Transistors
Low Noise, Dual Matched and Complex Bipolar Transistors
Specifications
| Transistor Type | NPN | |
| Maximum DC Collector Current | 0.1 A | |
| Maximum Collector Emitter Voltage | 45 V | |
| Package Type | TO-92 | |
| Mounting Type | Through Hole | |
| Maximum Power Dissipation | 0.625 W | |
| Minimum DC Current Gain | 200 | |
| Configuration | Single | |
| Maximum Collector Base Voltage | 50 V | |
| Maximum Emitter Base Voltage | 6 V | |
| Maximum Operating Frequency | 300 MHz | |
| Pin Count | 3 | |
| Number of Elements per Chip | 1 | |
| Width | 4.19mm | |
| Maximum Base Emitter Saturation Voltage | 0.7 V | |
| Minimum Operating Temperature | -55 °C | |
| Maximum Collector Emitter Saturation Voltage | 0.6 V | |
| Length | 5.2mm | |
| Dimensions | 5.33 x 5.2 x 4.19mm | |
| Height | 5.33mm | |
| Maximum Operating Temperature | +150 °C |
