10 x NXP BYW29EX-200 Ultra Fast Rectifier Diode, 8A, 200V 2-Pin TO-220F UPS SMPS - NXP

roll over the image to zoom in

£0.00
£5.99
RS 509-875
Earn0
reward points

In stock: 388

Sorry! We're out of stock

Add To Your Wishlist


    NXP

    VNXP BYW29EX-200,127 Rectifier Diode, 8A, 200V, 2-Pin TO-220F
    You will get a pack of 10 Diodes

    Glass passivated epitaxial rectifier diodes in a full pack plastic envelope,

    featuring low forward voltage drop, ultra-fast recovery times, soft recovery

    characteristic and guaranteed reverse surge and ESD capability. They are

    intended for use in switched mode power supplies and high frequency circuits in

    general where low conduction and switching losses are essential.


    • BrandNXP
    • Mfr. Part No.BYW29EX-200,127
    •
    NXP
    NXP BYW29EX-200,127 Rectifier Diode, 8A, 200V, 2-Pin TO-220F
    Product Details

    Rectifier Diodes, NXP Semiconductors

    Diodes and Rectifiers, NXP Semiconductors


    Specifications

    ConfigurationSingle
    Dimensions9.3 x 10.3 x 4.6mm
    Height9.3mm
    Length10.3mm
    Maximum Continuous Forward Current8A
    Maximum Operating Temperature+150 °C
    Minimum Operating Temperature-40 °C
    Mounting TypeThrough Hole
    Package TypeTO-220F
    Peak Forward Voltage1.3V
    Peak Non-Repetitive Forward Surge Current         0.088kA
    Peak Reverse Current0.01mA
    Peak Reverse Recovery Time25ns
    Peak Reverse Repetitive Voltage200V
    Pin Count2
    Rectifier TypeGeneral Purpose
    Width4.6mm

    Specification PDF Please CLICK HERE
