10 x Magnatec BD136 PNP Bipolar Transistor, 3 A 45 V, 3-pin SOT-32 - Magnatec
roll over the image to zoom in
£0.00
£5.99
RS 299-339
Magnatec
Magnatec BD136 PNP Bipolar Transistor, 3 A 45 V, 3-pin SOT-32
- You will receive a pack of 10
- BrandMagnatec
- Mfr. Part No.BD136
Product DetailsBipolar Transistors, Magnatec
A range of specialized bipolar transistors from Magnatec/Semelab which includes complementary Darlington Power Transistors and High-power, High-current TO3 devices.
Bipolar Transistors, Magnatec
SpecificationsCategory Bipolar Power Configuration Single Dimensions 10.8 x 7.8 x 2.7mm Height 10.8mm Length 7.8mm Maximum Collector Base Voltage 45 V Maximum Collector Emitter Saturation Voltage 0.5 V Maximum Collector Emitter Voltage 45 V Maximum DC Collector Current 3 A Maximum Emitter Base Voltage 5 V Maximum Operating Temperature +150 °C Maximum Power Dissipation 1.25 W Minimum DC Current Gain 25 Minimum Operating Temperature -65 °C Mounting Type Through Hole Number of Elements per Chip 1 Package Type SOT-32 Pin Count 3 Transistor Type PNP Width 2.7mm
For a Specification PDF Please CLICK HERE
