10 x Kingbright L-1553GDT Green LED 568nm Rectangular, Square Lens Through Hole - Kingbright
roll over the image to zoom in
£0.00
£5.49
RS 229-2576
Unit Quantity:
10
Unit Type:
Unit
Location:
TS 50J
Kingbright
Kingbright L-1553GDT, Rectangular Series Green LED, 568 nm Rectangular, Square Lens Through Hole package
- BMUK Part # :-229-2576
- BrandKingbright
- Mfr. Part No.L-1553GDT
- You will get a pack of 10 Leds
Product Details
Kingbright Through Hole Rectangular LED Series
The rectangular series of LEDs, from Kingbright, are reliable and rugged devices in a rectangular package. These LEDs offer excellent uniformity of light output, low power consumption and they have a long life time from solid state reliability. The rectangular LEDs are suitable for level indicators and are I.C. compatible. Available in a variety of package sizes, the rectangular LEDs also come in different colour options.
Viewing angle: 110°
Visible Light LEDs, Kingbright
Specifications
| LED Colours | Green | |
| Package Type | Rectangular | |
| Mounting Type | Through Hole | |
| Number of LEDs | 1 | |
| Luminous Intensity | 5 mcd | |
| Number of Pins | 2 | |
| Viewing Angle | 110 ° | |
| Lens Shape | Square | |
| Dominant Wavelength | 568 nm | |
| Dimensions | 5 x 5mm | |
| Series | Rectangular | |
| Lens Colour | Green | |
| LED Material | GaP |
To view the datasheet please Click Here
