10 x IRL3502 N-Chan MOSFET Transistor 110A 20V 5V Gate Arduino Raspberry PI PIC - International Rectifier
roll over the image to zoom in
£0.00
£14.99
ILR3502 Mosfet
Location:
BRA10G
International Rectifier
IR IRL3502 N-channel MOSFET Transistor, 110A, 20V, 3-pin TO-220
The Gate is on this transistor is perfect to run from a 5V logic drive maing this ideal for microcontroller use with Raspberry Pi, Basic Stamp, Arduino, PIC Micros etc,
Low ON resistance of only 0.007 Ohm, Pulse Current up to 420 Amps
You will receive 10 Transistors in an Anti Static bag, See our other items for these in larger QTY's
Product Details
HEXFET Power MOSFETs
HEXFET products are available in high performance packages to tackle the most challenging applications giving full flexibility in limited spaces. These Infineon products are designed to meet and exceed the energy efficiency and power density requirements of the sharpened next generation voltage regulation standards in computing applications.
N-channel - Enhancement mode
MOSFET Transistors,
| Category | Power Transistor | |
| Channel Mode | Enhancement | |
| Channel Type | N | |
| Configuration | Single | |
| Dimensions | 10 x 4.4 x 15.65mm | |
| Height | 15.65mm | |
| Length | 10mm | |
| Maximum Continuous Drain Current | 110 A | |
| Maximum Drain Source Resistance | 7 mΩ | |
| Maximum Drain Source Voltage | 20 V | |
| Maximum Gate Source Voltage | ±10 V | |
| Maximum Operating Temperature | +150 °C | |
| Maximum Power Dissipation | 140 W | |
| Minimum Operating Temperature | -55 °C | |
| Mounting Type | Through Hole | |
| Number of Elements per Chip | 1 | |
| Package Type | TO-220 | |
| Pin Count | 3 | |
| Typical Gate Charge @ Vgs | 27 nC@ 5 V | |
| Typical Input Capacitance @ Vds | 4700 pF@ 15 V | |
| Typical Turn-Off Delay Time | 96 ns | |
| Typical Turn-On Delay Time | 10 ns | |
| Width | 4.4mm |
Please see our other items for a wide range of Electronic components.
