10 x AVX 220uF 2.5V dc Tantalum Capacitor MnO2 Solid ±10% Tolerance TPS Series - AVX
roll over the image to zoom in
£0.00
£7.99
RS 699-3472
Unit Quantity:
10
Unit Type:
Unit
Location:
APR BOX J
AVX
AVX 220μF 2.5V dc Tantalum Capacitor MnO2 Solid ±10% Tolerance TPS Series
- BrandAVX
- Mfr. Part No.TPSB227K002R0150
- You will get a pack of 10 Capacitors
Image representative of range
Product Details
TPS Series 2.5 to 6.3Vdc
The TPS series of low ESR SMD capacitors from AVX are designed for use mainly in power supply applications. The TPS series of capacitor are available in 14 different case sizes.
Low ESR (equivalent series resistance)
High ripple current capability
Low power and heat dissipation
| Dimensions (mm) | |||||
| L | W | H | W1 | A | |
| Case code | +-0.2 | +-0.2 | +-0.2 | +-0.2 | +-0.3-0.2 |
| A | 3.2 | 1.6 | 1.6 | 1.2 | 0.8 |
| B | 3.5 | 2.8 | 1.9 | 2.2 | 0.8 |
| C | 6 | 3.2 | 2.6 | 2.2 | 1.3 |
| D | 7.3 | 4.3 | 2.9 | 2.4 | 1.3 |
| E | 7.3 | 4.3 | 4.1 | 2.4 | 1.3 |
| V | 7.3 | 6.1 | 3.45 | 3.1 | 1.4 |
| W | 6 | 3.2 | 1.5 | 2.2 | 1.3 |
Specifications
| Technology | MnO2 | |
| Capacitance | 220 µF | |
| Voltage | 2.5 V dc | |
| Mounting Type | Surface Mount | |
| Package/Case | 3528-21 | |
| Equivalent Series Resistance | 150mΩ | |
| Tolerance | ±10% | |
| Length | 3.5mm | |
| Depth | 2.8mm | |
| Height | 1.9mm | |
| Dimensions | 3.5 x 2.8 x 1.9mm | |
| Series | TPS | |
| Electrolyte Type | Solid | |
| Terminal Type | Surface Mount | |
| Maximum Operating Temperature | +125°C | |
| Leakage Current | 4.4 μA | |
| Tolerance Minus | -10% | |
| Minimum Operating Temperature | -55°C | |
| Dissipation Factor | 16% | |
| Tolerance Plus | +10% |
