1 x Vishay VS-SD600N22PC, High Voltage Diode, Stud Cathode 2200V 600A, 2-Pin - Vishay

roll over the image to zoom in

£0.00
£252.99
RS 395-9220
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 30A


    Vishay

    Vishay VS-SD600N22PC, Thread Mount High Voltage Diode, Stud Cathode, 2200V 600A, 2-Pin B 8


    • BMUK Part # :-395-9220
    • BrandVishay
    • Mfr. Part No.VS-SD600N22PC
    •
    •
    • You will get 1 Thread Mount High Voltage Diode










    Product Details

    Standard Recovery Rectifiers, over 40A

    Versatile and high-efficiency Standard Recovery Power Diodes in industry-standard package styles.

    Diodes and Rectifiers, Vishay Semiconductor

    Specifications


    		Diode ConfigurationStud Cathode

    		Maximum Continuous Forward Current600A

    		Number of Elements per Chip1

    		Rectifier TypeHigh Voltage

    		Peak Reverse Repetitive Voltage2200V

    		Mounting TypeThread Mount

    		Package TypeB 8

    		Diode TypeSilicon Junction

    		Peak Forward Voltage1.44V

    		Pin Count2

    		Length51.93mm

    		Width45mm

    		Height107.5mm

    		Peak Reverse Current35mA

    		Dimensions107.5 x 51.93 x 45mm

    		Maximum Operating Temperature+150 °C

    		Minimum Operating Temperature-40 °C

    		Peak Non-Repetitive Forward Surge Current11kA






    For a Specification PDF Please CLICK HERE
