1 x Vishay VS-1N1183RA, Thread Mount Switching Diode, Stud Anode, 50V 40A - Vishay

roll over the image to zoom in

£0.00
£13.49
RS 468-9168
Earn0
reward points

In stock: 40

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 6G


    Vishay





    Vishay VS-1N1183RA, Thread Mount Switching Diode, Stud Anode, 50V 40A, 2-Pin DO-5


    • BMUK Part # :-468-9168
    • BrandVishay
    • Mfr. Part No.VS-1N1183RA
    • Vishay
    •
    • You will get 1 Diode




    Vishay VS-1N1183RA, Thread Mount Switching Diode, Stud Anode, 50V 40A, 2-Pin DO-5




    Product Details

    Standard Recovery Rectifiers, 11A to 40A

    Versatile and high-efficiency Standard Recovery Power Diodes in industry-standard package styles.


    Diodes and Rectifiers, Vishay Semiconductor

    Specifications


    		Maximum Continuous Forward Current40A

    		Diode ConfigurationStud Anode

    		Number of Elements per Chip1

    		Rectifier TypeSwitching

    		Peak Reverse Repetitive Voltage50V

    		Mounting TypeThread Mount

    		Package TypeDO-5

    		Diode TypeSilicon Junction

    		Peak Forward Voltage1.3V

    		Pin Count2

    		Length20.02mm

    		Width17.35mm

    		Height22.9mm

    		Peak Reverse Current2.5mA

    		Dimensions22.9 x 20.02 x 17.35mm

    		Maximum Operating Temperature+190 °C

    		Minimum Operating Temperature-65 °C

    		Peak Non-Repetitive Forward Surge Current800A



    For a Specification PDF Please       CLICK HERE
