1 x Vishay IRF9640PBF P-channel MOSFET, 11A, 200V, 3-Pin TO-220AB - Vishay
roll over the image to zoom in
£0.00
£5.99
RS 541-1118
Unit Quantity:
1
Unit Type:
Unit
Country/Region of Manufacture:
Unknown
Location:
ES-9C
Vishay
Vishay IRF9640PBF P-channel MOSFET, 11 A, 200 V, 3-Pin TO-220AB
BMUK Part # :- 541-1118- BrandVishay
- Mfr Part No.IRF9640PBF
- You will get 1 Transistor
Product Details
P-Channel MOSFET, 100V to 400V, Vishay Semiconductor
MOSFET Transistors, Vishay Semiconductor
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
1
Length
10.41mm
Transistor Configuration
Single
Typical Turn-On Delay Time
14 ns
Brand
Vishay
Typical Turn-Off Delay Time
39 ns
Maximum Continuous Drain Current
11 A
Package Type
TO-220AB
Maximum Power Dissipation
125 W
Mounting Type
Through Hole
Minimum Operating Temperature
-55 °C
Width
4.7mm
Height
9.01mm
Minimum Gate Threshold Voltage
2V
Maximum Drain Source Resistance
500 mΩ
Maximum Drain Source Voltage
200 V
Pin Count
3
Dimensions
10.41 x 4.7 x 9.01mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
44 nC @ 10 V
Transistor Material
Si
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
1200 pF@ 25 V
Channel Type
P
Maximum Gate Source Voltage
-20 V, +20 V
