TRACOPOWER
TRACOPOWER Isolated DC-DC Converter THI 2411, Vin 21.6 → 26.4 V dc, Vout 5V dc, I/O isolation 2.5kV
- BMUK Part # :-699-2747
- BrandTRACOPOWER
- Mfr. Part No.THI 2411
- You will get 1 DC-DC Converter
Shop Categories  NEW RELEASES FEATURED PRODUCTS | 1 x TRACOPOWER Isolated DC-DC Converter THI 2411, Vin 21.6-26.4 V dc, Vout 5V dc
|    |
Product Details
Traco 2W DIP Single/Dual Output Medical Approved Regulated Isolated DC-DC Converter - THI Series
Regulated outputs
High isolation test voltage 6kV peak
Supplementary insulation for working voltage up to 250Vac
Short circuit protection
UL 94V-0 package material
24-pin DIP plastic package (dimensions 32x20x10mm)
Note
Derates 3% per °C above 60°C
MTBF to MIL-HDBK-217 E (25°C)
Standards
EN 60950, IEC 60950, IEC 60601, EN 60601-1
Traco - DIP 2W & 3W
Specifications
| Output Voltage | 5V dc | |
| Input Voltage Range | 21.6 → 26.4 V dc | |
| Input Voltage Nominal | 24 V dc | |
| Isolation Voltage | 2.5kV | |
| Output Current | 400mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Package | DIP 24, PDIP | |
| Efficiency | 62% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +75°C | |
| Load Regulation | ±1% | |
| Line Regulation | ±0.5% | |
| Ripple And Noise | 50mV Pk-Pk | |
| Series | THI | |
| Depth | 10mm | |
| MTBF | 600000h | |
| Length | 32mm | |
| Weight | 12g |
For a Specification PDF Please CLICK HERE
