1 x TRACOPOWER Isolated DC-DC Converter THI 0521, Vin 4.5-5.5 V dc, Vout ±12V dc - TRACOPOWER

roll over the image to zoom in

£0.00
£34.99
RS 699-2753
Earn0
reward points

In stock: 5

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 26A


    TRACOPOWER





    TRACOPOWER Isolated DC-DC Converter, Vin 4.5 → 5.5 V dc, Vout ±12V dc, I/O isolation 2.5kV


    • BMUK Part # :-699-2753
    • BrandTRACOPOWER
    • Mfr. Part No.THI 0521
    • TRACOPOWER
    •
    • You will get 1 DC-DC Converter














    Product Details

    Traco 2W DIP Single/Dual Output Medical Approved Regulated Isolated DC-DC Converter - THI Series

    Regulated outputs
    High isolation test voltage 6kV peak
    Supplementary insulation for working voltage up to 250Vac
    Short circuit protection
    UL 94V-0 package material
    24-pin DIP plastic package (dimensions 32x20x10mm)

    Note

    Derates 3% per °C above 60°C
    MTBF to MIL-HDBK-217 E (25°C)

    Standards

    EN 60950, IEC 60950, IEC 60601, EN 60601-1



    https://uk.rs-online.com/images60/E6447130-01.jpg



    Traco - DIP 2W & 3W

    Specifications

    Output Voltage±12V dc
    Input Voltage Range4.5 → 5.5 V dc
    Input Voltage Nominal5 V dc
    Isolation Voltage2.5kV
    Output Current80mA
    Mounting TypeThrough Hole
    Number of Outputs2
    PackageDIP 24, PDIP
    Efficiency57%
    Minimum Temperature-40°C
    Maximum Temperature+75°C
    Load Regulation±1%
    Line Regulation±0.5%
    Depth10mm
    MTBF600000h
    Length32mm
    Weight12g
    Ripple And Noise50mV Pk-Pk
    SeriesTHI





    For a Specification PDF Please  CLICK HERE
