1 x TRACOPOWER Isolated DC-DC Converter THD 10-4813WIN Vin 18-75 V dc Vout 15V - TRACOPOWER
roll over the image to zoom in
£0.00
£33.99
RS 815-9848
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 26G
TRACOPOWER
TRACOPOWER Isolated DC-DC Converter, Vin 18 → 75 V dc, Vout 15V dc, I/O isolation 1500V dc
- BMUK Part # :-815-9848
- BrandTRACOPOWER
- Mfr. Part No.THD 10-4813WIN
-
- You will get 1 DC-DC Converter
Product Details
Traco 10W Regulated Isolated DC-DC Converter - THD10WIN Series
The Tracopower THD 10-WIN is a Series of 10W regulated, isolated, high performance DC-DC converters with a low profile package and wide input voltage range. These isolated high performance DC-DC converters have an internal EMI filter to EN55022 class A and a full SMD-design. The THD 10-WIN features a DIP-24 standard package, which makes these DC-DC converters a drop in replacement for many cost critical applications.
Ultra wide 4:1 input voltage range
Internal EMI-filter meets EN 55022, class A without external components
High efficiency up to 87%
Operating temperature range –40°C to +85°C
No minimum load required
I/O isolation 1,500 VDC
Overload protection
Standards
UL/cUL 60950-1, IEC/EN 60950-1
Traco - 10W to 15W
Specifications
| Output Voltage | 15V dc | |
| Input Voltage Range | 18 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 1500V dc | |
| Output Current | 666mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Package | DIP 24 | |
| Efficiency | 87% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +85°C | |
| Load Regulation | 1.2% | |
| Line Regulation | 1% | |
| Depth | 10.2mm | |
| Weight | 17.3g | |
| Series | THD 10WIN | |
| Ripple And Noise | 100mV Pk-Pk | |
| MTBF | 1000000h | |
| Length | 31.8mm |
For a Specification PDF Please CLICK HERE
