1 x TRACOPOWER Isolated DC-DC Converter THB 3-4812, Vin 36-75V dc, Vout 12V dc - TRACOPOWER
roll over the image to zoom in
£0.00
£46.99
RS 437-972
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 25F
TRACOPOWER
TRACOPOWER Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout 12V dc, I/O isolation 4000V ac
- BMUK Part # :-437-972
- BrandTRACOPOWER
- Mfr. Part No.THB 3-4812
- You will get 1 DC-DC Converter
Product Details
Traco 3W DIP Single/Dual Output Regulated Isolated DC-DC Converter - THB 3 Series
Wide 2:1 input voltage range
Regulated outputs
Industrial & Medical safety approvals
4kVac rms input / output isolation
Isolation Test Voltage 6000 Vpeak
Supplementary and reinforced insulation for working voltages up to 300Vac
Built-in filter meets EN 55022, Class A and FCC, Level A without external components
Under-voltage shut-down, over-voltage and continuous short circuit protection
UL94V-0 package material
24-pin DIP with industry standard pin-out
Note
De-rating 3.5% per °C above 70°C.
MTBF to MIL-HDBK-217F (25°C).
Approvals
CB, CSA
Standards
EN 60950-1, UL60950-1, IEC 60950-1, CSA C22.2 No. 60950-1-03, EN 60601-1, EN 50124-1&2, UL 60601-1, IEC 60601-1, CSA C22.2 No. 601-1
Traco - DIP 1.98W to 8W
Specifications
| Output Voltage | 12V dc | |
| Input Voltage Range | 36 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 4000V ac | |
| Output Current | 250mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Package | DIP | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +85°C | |
| Series | THB 3 | |
| Depth | 10.5mm | |
| Length | 31.8mm |
