1 x TRACOPOWER Isolated DC-DC Converter THB 10-4812, Vin 36-75V dc, Vout 12V dc - TRACOPOWER
roll over the image to zoom in
£0.00
£77.99
RS 781-3323
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 9B
TRACOPOWER
TRACOPOWER Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout 12V dc, I/O isolation 4200V ac
- BMUK Part # :-781-3323
- BrandTRACOPOWER
- Mfr. Part No.THB 10-4812
-
- You will get 1 DC-DC Converter
Product Details
Traco 10W Regulated Isolated DC-DC Converter - THB Series
The Tracopower THB 10 series is a new range of high-performance DC/DC con¬verters with a reinforced insulation system. The THB 10 Converter comes in a compact package. This DC/DC converter features a wide 2:1 input voltage range and fully regulated output voltage. The Tracopower THB 10 converter offers an economical solution for demanding applications in industrial and medical instrumentation, requesting a certified supplementary or reinforced insulation system to comply with industrial or latest medical safety standards.
Supplementary and reinforced insulation
I/O isolation 4200 VACrms rated for 300 Vrms working voltage
Medical safety standards
Industrial safety to IEC/EN/UL 60950-1
Wide 2:1 input voltage ranges
Extended operating temperature range –40°C to 85°C max.
Input filter meets EN55022, class A
Continuous short-circuit protection
High reliability
3-year product warranty
Standards
EN 60950-1, EN 60601-1 3rd edition, UL 60950-1, UL 60601-1 , 2 x MOOP
Traco - 10W to 15W
Specifications
| Output Voltage | 12V dc | |
| Input Voltage Range | 36 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 4200V ac | |
| Output Current | 835mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Efficiency | 81% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +75°C | |
| Load Regulation | 1% | |
| Line Regulation | 0.5% | |
| Weight | 24.5g | |
| Ripple And Noise | 150mV Pk-Pk | |
| Series | THB 10 | |
| MTBF | 1000000h | |
| Depth | 12mm | |
| Length | 50.8mm |
