1 x TRACOPOWER Isolated DC-DC Converter TEN 60-4813N, Vin 36-75V dc, Vout 15V dc - TRACOPOWER

roll over the image to zoom in

£0.00
£144.99
RS 788-2711
Earn0
reward points

In stock: 6

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 26M


    TRACOPOWER





    TRACOPOWER Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout 15V dc, I/O isolation 1500V dc


    • BMUK Part # :-788-2711
    • BrandTRACOPOWER
    • Mfr. Part No.TEN 60-4813N
    • TRACOPOWER
    •
    • You will get 1 DC-DC Converter









    Product Details

    Traco 60W Regulated Isolated DC-DC Converter - TEN-60N Series

    The Traco Power TEN-60N series is a range of 60W DC/DC converters with a high efficiency of up to 92% and a compact footprint of only 2 x 1 inches. These Traco Power 60W DC/DC converters have a wide 2:1 input voltage range. The TEN-60N includes On/Off remote control and protection against over voltage, under voltage lockout and short circuit. These Traco Power DC/DC converters are the ideal solution for battery operated systems, thanks to their high efficiency and low input current characteristics. Typical applications for these 60W DC/DC converters include wireless networks, telecom/datacom, industry control systems and measurement equipment.

    2 x 1 inches metal package
    Wide 2:1 input voltage range 9–18, 18–36, 36–75 Vdc
    High efficiency up to 92%
    Adjustable output voltage
    No minimum load required
    Operating temperature range –40°C to +85°C
    Input filter to meet EN55022, class A
    Remote On/Off
    Under voltage lockout
    Lead free design, RoHS compliant
    3-year product warranty

    Standards

    UL/cUL 60950-1, IEC/EN 60950-1


    Traco - 40W to 60W

    Specifications

    Output Voltage15V dc
    Input Voltage Range36 → 75 V dc
    Input Voltage Nominal48 V dc
    Isolation Voltage1500V dc
    Output Current4A
    Mounting TypeThrough Hole
    Number of Outputs1
    Package1 x 2 in
    Efficiency92%
    Minimum Temperature-40°C
    Maximum Temperature+85°C
    Load Regulation0.5%
    Line Regulation0.2%
    Depth10.2mm
    Length50.8mm
    SeriesTEN 60N
    MTBF2600000h
    Weight33g
    Ripple And Noise200mV Pk-Pk




    For a Specification PDF Please  CLICK HERE
