1 x TRACOPOWER Isolated DC-DC Converter TEN 40-4834 Vin 36-75 V dc Vout 3.3V dc - TRACOPOWER
roll over the image to zoom in
£0.00
£92.99
RS 781-3535
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 25E
TRACOPOWER
TRACOPOWER Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout 3.3 V dc, ±15 V dc, I/O isolation 1500V dc
- BMUK Part # :-781-3535
- BrandTRACOPOWER
- Mfr. Part No.TEN 40-4834
- You will get 1 DC-DC Converter
Product Details
Traco 40W Single/Triple Output Regulated Isolated DC-DC Converter - TEN 40 Series
40W single/triple output regulated isolated DC-DC converters with a high power density. These single/triple output regulated isolated DC-DC converters have a high efficiency which allow an operating temperature range from -40°C to + 70°C. This series of single/triple output regulated isolated DC-DC converters are suitable for use in communication systems, industrial electronics and distributed power systems.
Very high power density: 40W in a 51x51x10mm package
Wide 2:1 input range
Models with single, and triple output
Very high efficiency up to 89%
Remote on/off
Short circuit protection
Shielded metal case
| Connection Data | ||
| Pin | Single O/P | Triple O/P |
| 1 | +Vin (Vcc) | +Vin (Vcc) |
| 2 | -Vin (GND) | -Vin (GND) |
| 3 | Remote on/off | Remote on/off |
| 4 | No function | +Vout 2 |
| 5 | -Sense | Common |
| 6 | +Sense | -Vout 3 |
| 7 | +Vout | +Vout 1 |
| 8 | -Vout | -Vout 1 |
| 9 | Trim | No function |
Note
Single o/p derates above 45°C, Triple o/p derates above 40°C.
Traco - 40W to 60W
Specifications
| Output Voltage | ±15 V dc, 3.3 V dc | |
| Input Voltage Range | 36 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 1500V dc | |
| Output Current | 6 A, 300 mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 3 | |
| Efficiency | 86% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +75°C | |
| Load Regulation | 2 %, 5 % | |
| Line Regulation | 1 %, 5 % | |
| Length | 50.8mm | |
| Weight | 65g | |
| Ripple And Noise | 50 mV Pk-Pk, 75 mV Pk-Pk | |
| Depth | 10.2mm | |
| Series | TEN 40 | |
| MTBF | 360000h |
TE Connectivity Black Heat Shrink Tubing, 9.5mm, 2:1, 10m Length
Product Details
DR-25 Heat shrink Tubing (Shrink Ratio 2:1)
Robust and flexible heat shrink tubing. It protects wires and cables against damage from chemicals, abrasion, and fluids. The tubing is ideal for use in high temperature environments as it has been specially designed for long term heat resistance and is flame retardant.
Features and Benefits
• Offers excellent protection and insulation
• Provides strain relief
• Performs well under long-term heat exposure
• The tubing is printed with the product description and size
• Shrink ratio of 2:1
• Use with System 25 range products for a complete cable harness system
Standards
VG95343 Part 5 Type D, VDE 0341/Pt 9005, AMS-DTL-23053/16, BS36-198 Part 3 10A.
High Temperature
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Sleeve Diameter | 9.5mm | |
| Shrunk Diameter | 4.8mm | |
| Colour | Black | |
| Sleeve Type | Heat Shrink | |
| Shrink Ratio | 2:1 | |
| Sleeve Length | 10m | |
| Material | Elastomer | |
| Minimum Operating Temperature | -75°C | |
| Maximum Operating Temperature | +150°C | |
| Dielectric Strength | 8kV/mm |
Microchip MCP7940M-I/SN Real Time Clock — Calendar, NV SRAM, 64B RAM 8-Pin SOIC
Product Details
MCP7940M I²C Real-Time Clock/Calendars
The Microchip MCP7940M is Real-Time Clock Calendar (RTCC) that supports I²C communications. The MCP7940M includes a digital trimming circuit for accuracy which can compensate for crystal tolerance and temperature.
The MCP7940M features a multi-functional output that can be configured as an alarm output, to output a selectable frequency square wave or as a general purpose output.
Features
2-Wire Serial Interface, I²C™ Compatible: I²C clock rate up to 400 kHzOn-Chip Digital Trimming/Calibration: ±1 ppm resolution, ±129 ppm range
Tracks Hours, Minutes, Seconds, Day of Week, Day, Month and Year
Leap Year Compensated to 2399
12/24 Hour Modes
Oscillator for 32.768 kHz Crystals: Optimised for 6-9 pF crystals
Dual Programmable Alarms
Versatile Output Pin
Wide Operating Voltage Range: 1.8V to 5.5V
Low Typical Timekeeping Current: 1.2μA at 3.3V
Real Time Clock Peripherals - Microchip
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Functions | Calendar, NV SRAM | |
| Date Format | DW:DM:M:Y | |
| Time Format | HH:MM:SS | |
| User RAM | 64B | |
| Bus Type | Serial-I2C | |
| Mounting Type | Surface Mount | |
| Package Type | SOIC | |
| Pin Count | 8 | |
| Dimensions | 4.9 x 3.9 x 1.25mm | |
| Length | 4.9mm | |
| Width | 3.9mm | |
| Height | 1.25mm | |
| Maximum Operating Supply Voltage | 5.5 V | |
| Minimum Operating Supply Voltage | 1.8 V | |
| Maximum Operating Temperature | +85 °C | |
| Minimum Operating Temperature | -40 °C |
