1 x TRACOPOWER Isolated DC-DC Converter TEN 40-4811N, Vin 36-75V dc, Vout 5V dc - TRACOPOWER

roll over the image to zoom in


£0.00
£76.99

RS 733-1998
Earn0
reward points

In stock: 12

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 24G


    TRACOPOWER

    TRACOPOWER Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout 5V dc, I/O isolation 1500V dc


    • BMUK Part # :-733-1998
    • BrandTRACOPOWER
    • Mfr. Part No.TEN 40-4811N
    •
    •
    • You will get 1 DC-DC Converter








    Product Details

    Traco 40W Single/Dual Output Regulated Isolated DC-DC Converter - TEN 40N Series

    40W single/dual output DC - DC converters with a high efficiency of up to 92% and a compact footprint of only 1.0" x 2.0". These 40W DC - DC converters have a wide 2:1 input voltage range and an output voltage which is tightly regulated. The output voltage can be adjusted using an external resistor. Typical applications for these 40W DC - DC converters include mobile equipment, instrumentation and distributed power architectures in communication and industrial electronics.

    Compact 1" x 2" x 0.4" package
    Efficiency of up to 92%
    Output voltage adjustable by external resistor
    Remote On/Off
    Short circuit and overvoltage protection
    EMC compliance to EN 55022, class A and FCC part 15, level A without external components

    Note

    MTBF to MIL-HDBK-217F (25°C)
    Power derates to 2.5% / K above 55°C
    For suitable heatsink see stock number 745-1240

    Standards

    UL/cUL 60950-1, IEC/EN 60950-1


    Traco - 40W to 60W

    Specifications


    Output Voltage5V dc

    Input Voltage Range36 → 75 V dc

    Input Voltage Nominal48 V dc

    Isolation Voltage1500V dc

    Output Current8A

    Mounting TypeThrough Hole

    Number of Outputs1

    Efficiency91%

    Minimum Temperature-40°C

    Maximum Temperature+80°C

    Load Regulation±1%

    Line Regulation±0.5%

    SeriesTEN 40N

    Depth11mm

    Length50.8mm

    Ripple And Noise100mV Pk-Pk

    MTBF328000h

    Weight30g




    For a Specification PDF Please CLICK HERE





    Thank you for looking, if you have any questions please ask or call us.
    Please see our other items for a wide range of Electronic components.

    TE Connectivity Black Heat Shrink Tubing, 9.5mm, 2:1, 10m Length







    Product Details

    DR-25 Heat shrink Tubing (Shrink Ratio 2:1)

    Robust and flexible heat shrink tubing. It protects wires and cables against damage from chemicals, abrasion, and fluids. The tubing is ideal for use in high temperature environments as it has been specially designed for long term heat resistance and is flame retardant.


    Features and Benefits
    • Offers excellent protection and insulation
    • Provides strain relief
    • Performs well under long-term heat exposure
    • The tubing is printed with the product description and size
    • Shrink ratio of 2:1
    • Use with System 25 range products for a complete cable harness system

    Standards

    VG95343 Part 5 Type D, VDE 0341/Pt 9005, AMS-DTL-23053/16, BS36-198 Part 3 10A.





    High Temperature



    Add product to Compare


    Specifications

    Not what you’re looking for? Select the attributes you require, then click the button below

    Sleeve Diameter9.5mm

    Shrunk Diameter4.8mm

    ColourBlack

    Sleeve TypeHeat Shrink

    Shrink Ratio2:1

    Sleeve Length10m

    MaterialElastomer

    Minimum Operating Temperature-75°C

    Maximum Operating Temperature+150°C

    Dielectric Strength8kV/mm

    Microchip MCP7940M-I/SN Real Time Clock — Calendar, NV SRAM, 64B RAM 8-Pin SOIC


    • BMUK Part # :-761-7627
    • BrandMicrochip
    • Mfr. Part No.MCP7940M-I/SN





    Product Details

    MCP7940M I²C Real-Time Clock/Calendars

    The Microchip MCP7940M is Real-Time Clock Calendar (RTCC) that supports I²C communications. The MCP7940M includes a digital trimming circuit for accuracy which can compensate for crystal tolerance and temperature.

    The MCP7940M features a multi-functional output that can be configured as an alarm output, to output a selectable frequency square wave or as a general purpose output.



    Features

    2-Wire Serial Interface, I²C™ Compatible: I²C clock rate up to 400 kHz
    On-Chip Digital Trimming/Calibration: ±1 ppm resolution, ±129 ppm range
    Tracks Hours, Minutes, Seconds, Day of Week, Day, Month and Year
    Leap Year Compensated to 2399
    12/24 Hour Modes
    Oscillator for 32.768 kHz Crystals: Optimised for 6-9 pF crystals
    Dual Programmable Alarms
    Versatile Output Pin
    Wide Operating Voltage Range: 1.8V to 5.5V
    Low Typical Timekeeping Current: 1.2μA at 3.3V




    Real Time Clock Peripherals - Microchip



    Add product to Compare


    Specifications

    Not what you’re looking for? Select the attributes you require, then click the button below

    FunctionsCalendar, NV SRAM

    Date FormatDW:DM:M:Y

    Time FormatHH:MM:SS

    User RAM64B

    Bus TypeSerial-I2C

    Mounting TypeSurface Mount

    Package TypeSOIC

    Pin Count8

    Dimensions4.9 x 3.9 x 1.25mm

    Length4.9mm

    Width3.9mm

    Height1.25mm

    Maximum Operating Supply Voltage5.5 V

    Minimum Operating Supply Voltage1.8 V

    Maximum Operating Temperature+85 °C

    Minimum Operating Temperature-40 °C
