1 x TRACOPOWER Isolated DC-DC Converter TEN 40-4810WIN, Vin 18-75V dc, Vout 3.3V - TRACOPOWER
roll over the image to zoom in
£0.00
£92.99
RS 781-3569
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 25B
TRACOPOWER
TRACOPOWER Isolated DC-DC Converter, Vin 18 → 75 V dc, Vout 3.3V dc, I/O isolation 1500V dc
- BMUK Part # :-781-3569
- BrandTRACOPOWER
- Mfr. Part No.TEN 40-4810WIN
- You will get 1 DC-DC Converter
Product Details
Traco 40W Single/Dual Output Regulated Isolated DC-DC Converter - TEN-40WIN Series
The Tracopower TEN 40WIN Series is a new range of isolated high performance DC/DC converters. Due to the very high efficiency of up to 90% these 40 W converters come with a very small footprint. The TEN 40WIN has an ultra wide 4:1 input voltage range and a tight output voltage regulation. The output voltage is ad¬justable by external resistor. Remote On/Off and protection against overpower and over voltage are standard features of these converters.
Typical applications for the TEN 40WIN DC/DC converters are in mobile equipment, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is limited.
Ultra compact size
Ultra wide 4:1 input voltage range
Excellent efficiency up to 90%
Output voltage adjustable
Operating temperature range –40°C to +75°C
Protection against short circuit and over voltage
Remote On/Off control
I/O isolation voltage 1500 Vdc
Standards
UL/c UL 60950-1, IEC/ EN 60950-1
Traco - 40W to 60W
Specifications
| Output Voltage | 3.3V dc | |
| Input Voltage Range | 18 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 1500V dc | |
| Output Current | 8A | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Efficiency | 89% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +75°C | |
| Load Regulation | ±0.5% | |
| Line Regulation | 0.5% | |
| Weight | 30g | |
| Ripple And Noise | 100mV Pk-Pk | |
| Length | 50.8mm | |
| Series | TEN 40WIN | |
| MTBF | 330000h | |
| Depth | 11mm |
For a Specification PDF Please CLICK HERE
