1 x TRACOPOWER Isolated DC-DC Converter TEN 40-1220, Vin 9-18V dc Vout 3.3V dc - TRACOPOWER

roll over the image to zoom in

£0.00
£132.99
RS 781-3468
Earn0
reward points

In stock: 2

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 26R


    TRACOPOWER





    TRACOPOWER Isolated DC-DC Converter, Vin 9 → 18 V dc, Vout 3.3 V dc, 5 V dc, I/O isolation 1500V dc


    • BMUK Part # :-781-3468
    • BrandTRACOPOWER
    • Mfr. Part No.TEN 40-1220
    •  TRACOPOWER
    •
    • You will get 1 DC-DC Converter














    Product Details

    Traco 40W Single/Triple Output Regulated Isolated DC-DC Converter - TEN 40 Series

    40W single/triple output regulated isolated DC-DC converters with a high power density. These single/triple output regulated isolated DC-DC converters have a high efficiency which allow an operating temperature range from -40°C to + 70°C. This series of single/triple output regulated isolated DC-DC converters are suitable for use in communication systems, industrial electronics and distributed power systems.

    Very high power density: 40W in a 51x51x10mm package
    Wide 2:1 input range
    Models with single, and triple output
    Very high efficiency up to 89%
    Remote on/off
    Short circuit protection
    Shielded metal case

    Connection Data
    PinSingle O/PTriple O/P
    1+Vin (Vcc)+Vin (Vcc)
    2-Vin (GND)-Vin (GND)
    3Remote on/offRemote on/off
    4No function+Vout 2
    5-SenseCommon
    6+Sense-Vout 3
    7+Vout+Vout 1
    8-Vout-Vout 1
    9TrimNo function

    Note

    Single o/p derates above 45°C, Triple o/p derates above 40°C.



    https://uk.rs-online.com/largeimages/L458113-01.gif



    Traco - 40W to 60W

    Specifications

    Output Voltage3.3 V dc, 5 V dc
    Input Voltage Range9 → 18 V dc
    Input Voltage Nominal12 V dc
    Isolation Voltage1500V dc
    Output Current8A
    Mounting TypeThrough Hole
    Number of Outputs2
    Efficiency85%
    Minimum Temperature-40°C
    Maximum Temperature+75°C
    Load Regulation1%
    Line Regulation1%
    Ripple And Noise50mV Pk-Pk
    Depth10.2mm
    SeriesTEN 40
    MTBF360000h
    Length50.8mm
    Weight65g



    For a Specification PDF Please     CLICK HERE
