1 x TRACOPOWER Isolated DC-DC Converter TEN 20-4821WIN Vin 18-75V dc Vout ±5V dc - TRACOPOWER
TRACOPOWER
TRACOPOWER Isolated DC-DC Converter, Vin 18 → 75 V dc, Vout ±5V dc, I/O isolation 1500V dc
- BMUK Part # :-438-317
- BrandTRACOPOWER
- Mfr. Part No.TEN 20-4821WIN
- You will get 1 DC-DC Converter
Traco 20W Single/Dual Output Regulated Isolated DC-DC Converter - TEN 20WIN Series
20W single/dual output regulated isolated high performance DC-DC converter modules with a compact low profile design and wide input voltage range. These high performance DC-DC converter modules have a high efficiency rating which allow an operating temperature range of -40°C to 85°C. Typical applications for these DC-DC converter modules include battery operated equipment and distributed power architectures in communication and industrial electronics.
High power density, 25.4x50.8x6mm package
Ultra-wide 4:1 input voltage range
Regulated outputs
Adjustable output voltage by using external resistors (single output models only)
1.5kV input / output isolation
High efficiency up to 89%
No minimum load required
Built-in filter meets EN 55022, Class A and FCC, Level A with external capacitor
Remote On/Off
Over-voltage, over-load and short circuit protection
Shielded metal case with insulated baseplate
Industry standard pin-out
Approvals
UL/cUL recognised
Standards
EN 60950-1, UL 60950-1, IEC 60950-1
Traco - 20W to 30W
Output Voltage | ±5V dc | |
Input Voltage Range | 18 → 75 V dc | |
Input Voltage Nominal | 48 V dc | |
Isolation Voltage | 1500V dc | |
Output Current | ±2A | |
Mounting Type | Through Hole | |
Number of Outputs | 2 | |
Package | 2 x 1 in | |
Efficiency | 89% | |
Minimum Temperature | -40°C | |
Maximum Temperature | +85°C | |
Load Regulation | ±5% | |
Line Regulation | ±0.2% | |
Depth | 10.2mm | |
MTBF | 1800000h | |
Series | TEN 20WIN | |
Length | 50.8mm | |
Width | 25.4mm | |
Ripple And Noise | 100mV Pk-Pk |
