1 x TRACOPOWER Isolated DC-DC Converter TEN 15-4823, Vin 36-75V dc, Vout ±15V dc - TRACOPOWER
roll over the image to zoom in
£0.00
£54.95
RS 433-8517
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 27E
TRACOPOWER
TRACOPOWER Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout ±15V dc, I/O isolation 1500V dc
- BMUK Part # :-433-8517
- BrandTRACOPOWER
- Mfr. Part No.TEN 15-4823
-
- You will get 1 DC-DC Converter
Product Details
Traco 15W Output Regulated Isolated DC-DC Converter - TEN15 Series
15W single/dual output regulated isolated DC-DC converters with SMD design, ceramic chip capacitors for high reliability and high efficiency. Typical applications for these regulated isolated DC-DC converters include communications, industrial systems and battery powered equipment.
Products not recommended for new designs please refer to the alternative at the bottom of the page
Wide 2:1 input voltage range
High power density
Regulated outputs
1.5kVdc input/output isolation
High efficiency up to 86%
Input filter to meet EN 55022 Class A and FCC Level A without external components
Continuous short circuit protection
SMD internal construction
Shielded metal case with insulated base plate
Industry standard pin-out
Approvals
UL/cUL
Standards
UL 60950-1, EN 60950-1, IEC 60950-1
Traco - 10W to 15W
Specifications
| Output Voltage | ±15V dc | |
| Input Voltage Range | 36 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 1500V dc | |
| Output Current | ±500mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 2 | |
| Package | 2 x 1 in | |
| Efficiency | 87% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +85°C | |
| Load Regulation | ±5% | |
| Line Regulation | ±0.5% | |
| Length | 50.8mm | |
| Depth | 10.2mm | |
| MTBF | 2300000h | |
| Ripple And Noise | 75mV Pk-Pk | |
| Series | TEN 15 | |
| Width | 25.4mm | |
| Weight | 27g |
