1 x TRACOPOWER Isolated DC-DC Converter TEN 12-4821, Vin 18-75V dc, Vout ±5V dc - TRACOPOWER

roll over the image to zoom in

£0.00
£76.99
RS 396-5360
Earn0
reward points

In stock: 3

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 30P


    TRACOPOWER





    TRACOPOWER Through Hole Isolated DC-DC Converter, Vin 18 → 75 V dc, I/O isolation 1500V dc, Vout ±5V dc


    • BMUK Part # :-396-5360
    • BrandTRACOPOWER
    • Mfr. Part No.TEN 12-4821
    •  TRACOPOWER
    •
    • You will get 1 DC-DC Converter



    TRACOPOWER Through Hole Isolated DC-DC Converter, Vin 18 → 75 V dc, I/O isolation 1500V dc, Vout ±5V dc

    Image representative of range



    Product Details

    Traco 12W Regulated Isolated DC-DC Converter - TEN12WI Series

    12W single/dual output regulated isolated DC-DC converters with a high power density and wide input voltage range. These regulated isolated DC-DC converters have internal filtering to EN 55022 level A and a wide operating temperature range. Typical applications include communications, industrial systems and battery powered mobile equipment.

    Ultra-wide 4:1 input voltage range
    1.5kVdc input/output isolation
    Small package - high power density
    High efficiency up to 84%
    Input filter to meet EN 55022 Class A and FCC Level A without external components
    Continuous short circuit protection
    SMD internal construction
    Long life and high reliability (MTBF >700000 hours)
    Metal case with insulated base plate
    Industry standard pin-out

    Connection Data
    PinSingle outputDual output
    1+Vin (Vcc)+Vin (Vcc)
    2-Vin (GND)-Vin (GND)
    3+Vout+Vout
    4No pinCommon
    5-Vout-Vout

    Note

    MTBF to MIL-HDBK-217 E
    Operating temperature is with derating of 2% per °C above 60 °C.

    Approvals

    cULus

    Standards

    UL 1950, EN 60950, IEC 60950. Compliance up to 60 VDC input voltage (SELV limit)



    https://uk.rs-online.com/largeimages/L396529-01.gif
    https://uk.rs-online.com/largeimages/LF396529-01.gif



    Traco - 10W to 15W

    Specifications

    Output Voltage±5V dc
    Input Voltage Range18 → 75 V dc
    Input Voltage Nominal48 V dc
    Isolation Voltage1500V dc
    Output Current±1A
    Mounting TypeThrough Hole
    Number of Outputs2
    Package1 x 2 in
    Minimum Temperature-40°C
    Maximum Temperature+85°C
    Load Regulation±0.5%
    Line Regulation±0.5%
    Ripple And Noise50mV
    Length25.4mm
    Depth10.2mm
    SeriesTEN 12







    For a Specification PDF Please  CLICK HERE
