1 x Toshiba TK40J60U(F) N-channel MOSFET, 40A, 600V TK, 3-Pin TO-3PN - Toshiba
roll over the image to zoom in
£0.00
£10.99
RS 760-3142
Unit Quantity:
1
Unit Type:
Unit
Location:
ES-4J
Toshiba
Toshiba TK40J60U(F) N-channel MOSFET, 40 A, 600 V TK, 3-Pin TO-3PN
BMUK Part # :- 760-3142- BrandToshiba
- Mfr Part No.TK40J60U(F)
- You will get 1 Transistor
Product Details
MOSFET Transistors, Toshiba
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
1
Length
15.5mm
Transistor Configuration
Single
Typical Turn-On Delay Time
120 ns
Brand
Toshiba
Typical Turn-Off Delay Time
160 ns
Maximum Continuous Drain Current
40 A
Package Type
TO-3PN
Maximum Power Dissipation
320 W
Series
TK
Mounting Type
Through Hole
Width
4.5mm
Maximum Gate Threshold Voltage
5V
Height
20mm
Maximum Drain Source Resistance
80 mΩ
Maximum Drain Source Voltage
600 V
Pin Count
3
Dimensions
15.5 x 4.5 x 20mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
55 nC @ 10 V
Transistor Material
Si
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
3400 pF@ 10 V
Channel Type
N
Maximum Gate Source Voltage
-30 V, +30 V
