1 x Toko RFID Antenna #6DPF-1643G1553J-13, 1553.25MHz - Toko
roll over the image to zoom in
£0.00
£7.99
RS 752-1084
Type:
Antenna
Unit Quantity:
1
Location:
TS 51C
Toko
Toko RFID Antenna #6DPF-1643G1553J-13, 1553.25 MHz
- BMUK Part # :-752-1084
- BrandToko
- Mfr. Part No.6DPF-1643G1553J-13
-
- You will get 1 Antenna
Product Details
Toko 6DPF Series
Frequency Range: 700 - 1500MHz
Temperature Range: -40°C - +85°C
| Tx or Rx | Centre Frequency (MHz) | Bandwidth (fo ± MHz) | Insertion Loss (dB) Max. | Ripple in BW Max. | V.S.W.R. in BW Max. | Attenuation (dB) Min. (MHz) | Max. Input Power (W) | |
| #6DPF-1216A1252A-11 | Tx | 1216.5 | 2.5 | 2.7 | 0.5 | 2.0 | 28 (1250) | 1.0 |
| Rx | 1252.5 | 2.5 | 2.7 | 0.5 | 2.0 | 28 (1219) | ||
| #6DPF-1643G1553J-13 | Tx | 1643.5 | 17.0 | 2.5 | 1.0 | 2.0 | 40, 28 (1480, 1559) | 1.0 |
| Rx | 1553.25 | 23.25 | 2.5 | 1.0 | 2.0 | 7, 20 (1600,1626.5) |
Antenna Duplexers
Specifications
Supported Frequency Bands | 1553.25 MHz |
