1 x TI ULN2003AD NPN Darlington Driver Array 7-Way 50V 0.5A TTL 5V CMOS SOIC-16 - Texas Instruments

roll over the image to zoom in

£0.00
£4.99
RS 858-196
Earn0
reward points

In stock: 40

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS LB 2J


    Texas Instruments

    Texas Instruments ULN2003AD, 7-element NPN Darlington Transistor Array, 0.5 A 50 V, 16-Pin SOIC


    BMUK Part # :-858-196BrandTexas InstrumentsMfr. Part No.ULN2003AD
     You will get 1 Transistor






    Product Details

    Darlington Transistor Arrays, Texas Instruments

    This array of seven Darlington transistor circuits is able to drive high output current.


    Darlington Transistor Drivers

    Specifications


    Transistor TypeNPN
    Maximum Continuous Collector Current0.5 A
    Maximum Collector Emitter Voltage50 V
    Maximum Emitter Base Voltage50 V
    Package TypeSOIC
    Mounting TypeSurface Mount
    Pin Count16
    Transistor ConfigurationCommon Emitter
    Number of Elements per Chip7
    Maximum Collector Emitter Saturation Voltage1.6 V
    Height1.58mm
    Maximum Operating Temperature+70 °C
    Length9.9mm
    Dimensions9.9 x 3.91 x 1.58mm
    Width3.91mm
    Minimum Operating Temperature-20 °C



    To view the datasheet please Click Here
